2 pin JST PH 2.0mm Through Hole Header Vertical Straight Top Entry

Product Description

The 2 Pin JST PH 2.0mm Through Hole Header Vertical Straight Top Entry is a compact and reliable PCB-mounted wire-to-board connector designed for secure electrical connections in a wide range of electronic applications. Featuring a 2.0mm pitch, 2-pin configuration, and vertical top-entry design, this connector is widely used in consumer electronics, drones, robotics, IoT devices, battery management systems (BMS), LED lighting, embedded electronics, and industrial control systems.

Designed to match the JST PH series specifications, this connector provides a secure and polarized connection that helps prevent incorrect mating while ensuring reliable electrical performance. Its through-hole (THT) mounting design offers excellent mechanical strength and durability, making it suitable for applications subject to vibration or frequent use.

The connector is manufactured with high-quality copper alloy contacts and tin-plated terminals, ensuring low contact resistance, excellent conductivity, and long-term corrosion resistance. The durable high-temperature thermoplastic housing provides strong insulation and maintains structural integrity during soldering and prolonged operation.

The vertical straight top-entry design allows wires to connect from the top of the PCB, making it ideal for compact electronic assemblies where efficient use of board space and simple cable routing are important.

Whether you're building a drone, designing a battery-powered device, developing an IoT project, or repairing electronic equipment, the 2 Pin JST PH 2.0mm Through Hole Header offers a dependable, compact, and cost-effective connection solution.

Key Features

• 2 Pin JST PH compatible connector
• 2.0mm pitch wire-to-board connector
• Vertical straight top-entry design
• Through-hole (THT) PCB mounting
• Polarized housing prevents incorrect connections
• Tin-plated copper alloy contacts
• Low contact resistance for reliable electrical performance
• High-temperature thermoplastic insulating housing
• Strong mechanical retention after soldering
• Compact design for space-constrained PCB layouts
• Easy to solder and install

Applications & Use Cases

The 2 Pin JST PH 2.0mm Through Hole Header is commonly used in:

• Drones and UAV electronics
• Battery Management Systems (BMS)
• Lithium-ion and LiPo battery packs
• Robotics and automation projects
• IoT devices
• Embedded systems
• LED lighting modules
• Consumer electronics
• Sensors and control modules
• Arduino and Raspberry Pi projects
• DIY electronics and PCB prototyping
• Industrial electronic equipment

Technical Specifications

• Connector Type: JST PH Compatible Header
• Number of Pins: 2
• Pitch: 2.0mm
• Mounting Type: Through-Hole (THT)
• Orientation: Vertical Straight (Top Entry)
• Contact Material: Copper Alloy
• Contact Plating: Tin Plated
• Housing Material: High-temperature Thermoplastic
• Rated Current: Up to 2A
• Rated Voltage: 100V AC/DC
• Insulation Resistance: ≥1000MΩ
• Contact Resistance: ≤20mΩ
• Operating Temperature: -25°C to +85°C
• Mating Connector: JST PH 2.0mm Female Housing with Crimp Terminals

Why Choose This Connector?

The 2 Pin JST PH 2.0mm Through Hole Header is an excellent choice for compact electronic designs that require a reliable and polarized wire-to-board connection. Its through-hole construction provides superior mechanical stability compared to surface-mount alternatives, while the standardized 2.0mm pitch ensures compatibility with widely available JST PH cable assemblies.

Its compact size, dependable electrical performance, and ease of installation make it ideal for drones, robotics, battery-powered devices, and a wide variety of embedded electronic applications.

Package Includes

• 1 × 2 Pin JST PH 2.0mm Through Hole Header Vertical Straight Top Entry Connector
