9 pin JST PH 2.0mm SMT Header Vertical Straight Top Entry

Product Description

The 9 Pin JST PH 2.0mm SMT Header Vertical Straight Top Entry is a compact and reliable surface-mount wire-to-board connector designed to provide secure electrical connections in space-constrained electronic applications. Featuring a 2.0mm pitch, 9-pin configuration, and vertical straight top-entry design, this connector is suitable for applications requiring multiple signal connections while maintaining a compact PCB layout.

Compatible with the JST PH 2.0mm series, this header is designed for Surface Mount Technology (SMT) assembly, making it suitable for automated PCB manufacturing and high-density circuit board designs. The vertical top-entry orientation allows the mating connector to connect directly above the PCB, helping optimize component placement and cable management.

The connector features high-quality copper alloy contacts with tin plating, providing excellent electrical conductivity, low contact resistance, and long-term reliability. Its high-temperature thermoplastic housing offers superior insulation and withstands standard SMT reflow soldering processes, ensuring durability in demanding electronic applications.

Ideal for drones, robotics, IoT devices, sensors, embedded electronics, battery systems, and consumer electronics, the 9 Pin JST PH 2.0mm SMT Header Vertical Straight Top Entry provides a dependable and space-efficient wire-to-board connection solution.

Key Features

• JST PH 2.0mm compatible SMT header
• 9-pin wire-to-board connector
• 2.0mm pitch
• Surface Mount Technology (SMT) design
• Vertical straight top-entry orientation
• Polarized connector design for secure mating
• Tin-plated copper alloy contacts
• High-temperature thermoplastic housing
• Suitable for automated PCB assembly
• Compact and space-saving design
• Reliable electrical and mechanical performance

Applications & Use Cases

The 9 Pin JST PH 2.0mm SMT Vertical Header is commonly used in:

• Drones and UAV electronics
• Robotics and automation systems
• Battery Management Systems (BMS)
• IoT devices
• Sensor modules
• Embedded control systems
• LED lighting systems
• Consumer electronics
• Arduino-compatible hardware
• Industrial control equipment
• DIY electronics and PCB prototyping

Technical Specifications

• Connector Type: JST PH Compatible SMT Header
• Number of Pins: 9
• Pitch: 2.0mm
• Mounting Type: Surface Mount Technology (SMT)
• Orientation: Vertical Straight (Top Entry)
• Contact Material: Copper Alloy
• Contact Plating: Tin Plated
• Housing Material: High-temperature Thermoplastic
• Rated Voltage: 100V AC/DC
• Rated Current: Up to 2A
• Operating Temperature: -25°C to +85°C
• Compatible Connector: JST PH 2.0mm 9-pin Female Housing

Why Choose This Header?

The 9 Pin JST PH 2.0mm SMT Header Vertical Straight Top Entry is designed for applications requiring a compact, reliable, and high-density PCB connection. Its SMT mounting capability supports efficient production assembly, while the vertical design saves board space and provides organized cable routing. It is an excellent choice for drones, robotics, embedded electronics, and other compact electronic systems.

Package Includes

• 1 × 9 Pin JST PH 2.0mm SMT Header Vertical Straight Top Entry Connector
